Orientation and Layout

Orientation

Entry
Function Bar
>
Prepare
>
Orient
Default Combination Key
O
R

Set the orientation for the selected 3D model automatically before adding supports. The line defined by two points with the longest distance on the surface of the model will be considered as the vertical axis when applying auto orientation.

Layout

Entry
Function Bar
>
Prepare
>
Layout
Default Combination Key
L
O

Set the layout for the selected 3D model automatically before adding supports. The layout defines how the model will be positioned and oriented on the build plate.

CHITUBOX supports multi-platform layouts, if your current build plate can't accommodate all objects, additional platforms will be automatically created to fit everything.

NOTE

If the size of a single model exceeds the build plate limits, CHITUBOX simply move it out of the build plate, and will not automatically create a new platform for it.

Options explained:
